pipe bend 90° R=2D, diam. 100x2 mm
KMH item number
1021016e
steel DC01, powder coated (RAL 7032), with earthing lugs
Availability
pipe bend 90° R=2D, diam. 100x2 mm, steel DC01, powder coated inside and outside (RAL 7032), with earthing lugs
| Remark | measurements for 2 mm piping |
|---|---|
| dimensions dlw | 99 mm |
| dimensions dn | 100 mm |
| dimensions r | 200 mm |
| coating | powder coated |
| grounding lug | yes |
| degree | 90 ° |
| material | DC01 |
| nominal width | 100 |
| radius | R=2D |
| material thickness | 2 mm |
| conductivity | yes |
| Commodity statistical number | 7307 99 80 |
| weight in kg | 1,6000 |
| Remark | mistakes and amendments reserved |
