throttle valve, diam. 80x1,5 mm
KMH item number
0811075
steel DC01, powder coated (RAL 7032)
Availability
throttle valve, diam. 80x1,5 mm, steel DC01, powder coated inside and outside (RAL 7032)
| Remark | measurements for 2 mm piping |
|---|---|
| dimensions a | 100 mm |
| dimensions b | 97 mm |
| dimensions c | 60 mm |
| dimensions dlw | 78 mm |
| dimensions dn | 80 mm |
| coating | powder coated |
| activity | manually operated |
| flap seal | no |
| grounding lug | no |
| material | DC01 |
| nominal width | 80 |
| maximum temperature | °C |
| minimum temperature | °C |
| maximum temperature (short-term) | °C |
| material thickness | 1,5 mm |
| conductivity | no |
| Commodity statistical number | 8481 80 85 |
| weight in kg | 0,9900 |
| Remark | mistakes and amendments reserved |
